Blackmagic Design MultiView 4
75,00 € + IVA /dia
O Blackmagic Design MultiView 4 possui quatro entradas 6G-SDI de 10 bits que permitem monitorar fontes SD, HD, ou 4K, em qualquer combinação de monitores ou TV’s Ultra HD. Isto permite aproveitar os monitores de alta resolução para visualizar cada fonte com maior clareza. O MultiView 4 permite uma transmissão a 2×2 ecrãs, com cada entrada totalmente ressincronizada. São fornecidas uma saída 6G-SDI e uma saída HDMI com multiview, bem como uma saída de loop para cada entrada 6G-SDI, para transmitir os sinais para dispositivos adicionais.
Pontos chave:
- 4x 6G-SDI Inputs with Loop Outputs
- 1x SDI & 1x HDMI MultiView Outputs
- Supports SD, HD, UHD 4K, DCI 4K
- Independent Inputs Allow Mixing Formats
Artigos incluídos neste aluguer
- 1x Blackmagic Design MultiView 4
- 1x 12V Universal Power Supply
Produtos Relacionados
-
Mini Converter SDI to HDMI
Referência: 2300325,00 € + IVA /dia Seleccionar Datas -
Mini Converter HEAVY DUTY SDI to Analog
Referência: 2300225,00 € + IVA /dia Seleccionar Datas -
Conversor de Bateria SDI to HDMI
Referência: 2300125,00 € + IVA /dia Seleccionar Datas -
Decimator – MD-HX conversor HDMI-SDI bidireccional
Referência: 2300525,00 € + IVA /dia Seleccionar Datas
Informação Adicional
Housed in a 1 RU machined aluminum frame, the MultiView 4 is ready for use in the studio, broadcast truck, or even on location. It can be controlled with the included control software via the Ethernet port or by an optional Teranex front panel (not included). For easy integration into any facility, a built-in multi-voltage power supply supports 90 to 240 VAC, or you can power the unit by 48 VDC PoE+.
- Native Ultra HD multi-view output
- 4x 6G-SDI inputs; accepts SD, HD, Ultra HD, and DCI 4K signals
- Supports Ultra HD 4K (3840×2160) up to 30p; DCI 4K (4096×2160) at 24p
- 1x 6G-SDI and 1x HDMI multi-view outputs
- 4x SDI loop outputs
- 2×2 multi-view configurations
- 2-channel audio meters for each view
- 16×9 SD support
- Tally support with ATEM switchers via optional Teranex Mini Smart Panel
- 1 RU machined aluminum chassis
- Software control over Ethernet; supports Videohub router protocol
- Built-in 90 to 240 VAC power supply
- IEC power cable required
- Supports PoE+ 48 VDC
Blackmagic Design MultiView 4 Specs
| SDI Video Input | 4 x 10-bit SD/HD/6G-SDI |
| SDI Video Output | 4 x 10-bit SD/HD/6G-SDI loop outputs |
| Multi-View Outputs | 1 x 10-bit HD/6G-SDI 1 x HDMI, type A (supports EDID of the monitor) |
| Multi-Rate Support | Auto detection of SD, HD, or 6G-SDI. Simultaneous viewing of 4K, HD, and SD video. |
| Updates | USB 2.0 high speed (480 Mb/s) interface or via Ethernet |
| Control | 1 x RJ45 Ethernet |
| Configuration | Via RJ45 Ethernet or USB 2.0 for firmware updates and IP address setting |
| Reclocking | On all SDI outputs; auto switching between SD, HD, or 6G-SDI video |
| Format Support | SD Format Support 625/25 PAL 525/29.97 NTSCHD Format Support 720p 50/59.94/60 1080i 50/59.94/60 1080PsF 23.98/24/25/29.97/30 1080p 23.98/24/25/29.97/30/50/59.94/602K Format Support 2048x1080p 23.98/24/25 2048x1080PsF 23.98/24/254K Format Support 3840x2160p 23.98/24/25/29.97/30 4096x2160p 24 |
| SDI Compliance | SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 310M, SMPTE 425M-B, ITU-R BT.656, and ITU-R BT.601 |
| SDI Video Rates | SD-SDI: 270 Mb/s HD-SDI: 1.5 Gb/s 3G-SDI: 3 Gb/s 6G-SDI: 6 Gb/s |
| SDI Video Sampling | 4:2:2 and 4:4:4 |
| SDI Color Precision | 4:2:2 and 4:4:4 10-bit |
| SDI Color Space | Inputs: YUV or RGB Outputs: YUV |
| SDI Audio Sampling | 48 kHz and 24-bit |
| SDI Metadata Support | Video payload identification ancillary data as per SMPTE 352M |
| Software Control | Multi-view control software included free for Windows and Mac OS X |
| Internal Software Upgrade | Via included updater application |
| Power Supply | IEC power cable required 90 to 240 VAC input PoE+: 48 VDC |
| Power Consumption | 16 W |
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Storage Temperature | -4 to 113°F (-20 to 45°C) |
| Relative Humidity | 0 to 90% non-condensing |
| Rack Space | 1 RU |
| Dimensions (W x H x D) | 5.51 x 1.75 x 6.69″ (13.99 x 4.45 x 16.99 cm) |
| Weight | 1.28 lb (0.58 kg) |
